High Alumina Bricks Series

First grade high alumina brick

Second grade high alumina brick

Third grade high alumina brick

Special grade high alumina brick

  Description

High alumina brick is a kind of refractory, the main component of which is Al2O3. If Al2O3 content is higher than 90%, it is called corundum brick. Due to different resources, the standards of different countries are not completely consistent. For example, in European countries, the lower limit of Al2O3 content for high alumina refractories is 42%. In China, Al2O3 content in high alumina brick is generally divided into three grades: Grade I - Al2O3 content > 75%; grade II - Al2O3 content is 60-75%; grade III - Al2O3 content is 48-60%.

  Technical Data:

Items First grade high alumina brick Second grade high alumina brick Third grade high alumina brick Special grade high alumina brick
LZ-75 LZ-65 LZ-55 LZ-80
Al2O3 % ≥ 75 65 55 82
Fe2O3 % ≤ 2.5 2.5 2.6 2.0
Bulk Density g/cm3 2.5 2.4 2.3 2.6
Cold Crushing Strength MPa ≥ 70 60 50 80
0.2MPa Refractoriness Under Load  ℃ 1510 1460 1420 1550
Refractoriness ℃ ≥ 1790 1770 1770 1790
Apparent Porosity % ≤ 22 23 24 21
Reheating Linear Change 1450℃×2h  % -0.3 -0.4 -0.4 -0.2

  Application:

High alumina bricks are popularly used for the masonry of industrial kilns inner linings, such as blast furnaces, hot blast furnaces, electric furnace top, reverberator, rotary cement kiln and so on. Besides, high alumina bricks are also widely used as regenerative checker bricks, stopper of continuous casting system, nozzle bricks, etc.
